    Metal Slant Bed Millturn Precision Machine With Syntec Cnc Control System

    Ask Lasest Price
    Price : Contact Us
    Delivery Time : 45-60 days
    Payment Terms : T/T
    Supply Ability : 20 units/month
    • Product Details
    • Company Profile

    Metal Slant Bed Millturn Precision Machine With Syntec Cnc Control System

    Universal New CNC Turning Metal Lathe Machine Price Horizontal Slant Bed Lathe Cnc Lathe Machine
    Metal Slant Bed Millturn Precision Machine With Syntec Cnc Control System

    precisely torno lathe sale for cnc bed slant bmt driven tool turning machin metal lathes

    Description

    Advanced High-Travel CNC Lathe with Enhanced Capabilities

    This advanced high-travel turning and milling composite CNC lathe is designed with an inclined bed to facilitate efficient chip evacuation. Building on the W7 model, it provides extended travel and swing diameters ranging from 1 meter to 3 meters. Customizable options include the integration of a Y-axis for enhanced machining flexibility and center supports for added stability. Larger spindle sizes are also available upon request, making this machine highly adaptable to various production requirements.

    Specification

    ParameterUnitW7-8/6CYD
    Double Spindle Interpolated Y-axis Turning and Milling Machine Tool
    Max. Turning DiametermmΦ300
    Max. Machining Lengthmm550
    Max. Swing Diametermm1st Spindle: Φ500; 2nd Spindle: Φ220
    Bar Feeding Diametermm1st Spindle: <Φ52; 2nd Spindle: <Φ46
    Spindle Boremm1st Spindle: Φ66; 2nd Spindle: Φ56
    Max. Spindle SpeedRPM1st Spindle: 3500; 2nd Spindle: 4000
    X-axis Travelmm220
    Y-axis Travelmm110
    Z-axis Travelmm600
    B-axis (Tailstock) Travelmm610

    Other information
    CNC or not
    slant bed or not
    Hydraulic System
    CNC
    slant
    Channels
    Recommend Products

    Products Description
    Metal Slant Bed Millturn Precision Machine With Syntec Cnc Control System
    Product Paramenters

    Details Display
    Metal Slant Bed Millturn Precision Machine With Syntec Cnc Control System
    The machine's transmission system employs high-precision ball screws and high-rigidity,high-speed roller guides.
    Metal Slant Bed Millturn Precision Machine With Syntec Cnc Control System
    The X-axis and Z-axis feature high-rigidity linear slides with anoptimally calculated track span,offering low resistance,highprecision,and speeds up to 22m/min.This enhances workefficiency and reduces processing time.
    The Driven Tool Turret can perform various machining operations such as drilling,milling,and tapping,which meansthat a single machine can complete more types of tasks,enhancing the flexibility and range of the machine.Overall,thelathe Driven Tool Turret significantly improves the efficiencyand quality of lathe machining by providing multi-functionalmachining capabilities,quick tool changes,high precision,andautomated operations.It is an indispensable and importantcomponent in modern precision manufacturing.

    Our CNC turret lathes are equipped with avariety of mechanicalspindles to choose from.These spindles are notable for theirhigh rigidity,minimal noise and vibration,and,crucially,theirability to perform high-precision operations.The precisionof movement and the robustness of the spindle componentsplay a pivotal role in defining the quality of processing and theefficiency of cutting operations.
    NSK super-precision bearings,featuring high running accuracy,rapid speed capabilities,and exceptional precision,are ideallysuited for spindle units in machine tools.These bearings arespecifically engineered to reduce noise,vibration,and heatgeneration,enhancing overall performance.
    In addition,the eletric spindle can be selected.The advantagesof an electric spindle include high speed,high precision,widerange of speed variation,high rigidity,precise control,energysaving and environmental protection,and low maintenancecosts.Overall,the machine tool electric spindle has significantadvantages in improving processing efficiency,precision,and quality,and therefore,it is widely used in modernmanufacturing.



    Metal Slant Bed Millturn Precision Machine With Syntec Cnc Control System
    Equipment Display
    Metal Slant Bed Millturn Precision Machine With Syntec Cnc Control System
    Metal Slant Bed Millturn Precision Machine With Syntec Cnc Control System
    Metal Slant Bed Millturn Precision Machine With Syntec Cnc Control System
